Quiz - GATEWAY DATA LOGGER EXCGLA01 (ENG)

1. Final quiz.

With this quiz you can test your knowledge. Are you ready? Then start and don't worry about making mistakes, you can take the test again as many times as you want.

Question Title

* 1. This device, dedicated to data collection for energy management, is equipped with ...

one RS485 port and two Ethernet ports.

three RS485 ports.

one RS485 port and one Ethernet port.

Question Title

* 2. A typical monitoring scenario is with two or more instruments connected in cascade to each other. In this case, the connection to the gateway datalogger EXCGLA01 is direct. You can connect the instruments in cascade to the terminal of the data logger gateway through an RS485 cable. To terminate the chain correctly, it is sufficient to make a bridge between cable A and ... to have the terminal resistance of the chain. Complete the sentence:

Question Title

* 3. When the instruments are connected in an RS485 chain separate from the gateway data logger, it is possible to put them in communication through the local network. Starting from a network switch connected to the local network, with an ethernet cable it is possible to connect to ...

the gateway data logger

the energy counter

the RS485/Ethernet converter (EXCCON01)

Question Title

* 4. When setting up the gateway data logger EXCGLA01 from a PC, you can choose the most suitable monitoring scenario for each device.

False

True

Question Title

* 5. Which are the pre-requisites to be considered to
take the most of EXCGLA01?

The IP address assigned to EXCGLA01 must be enabled to browse the internet if data transfer to remote servers is desired

EXCGLA01 must be connected to the local network (LAN), possibly by a static IP address or a dynamic IP assigned by a DHCP server where EXCGLA01 MAC address is coupled to a known IP;

The devices to be monitored must be equipped with RS485 or ethernet ports;

Question Title

* 6. How many devices can be connected to EXCGLA01?

The devices can be freely distributed between the RS485 and the ethernet port until the max number of 31 devices.

The devices can be freely distributed between the RS485 and the ethernet port until the max number of 24 devices.

The devices can be freely distributed between the RS485 and the ethernet port until the max number of 256 devices.
